Ingersoll Rand product
Cordless Precision Fastening Systems
- Provides up to 32 fully programmable configurations on a single tool
- Ergonomic Tightening System (ETS) improves operator comfort and minimizes risk of injury
- Available in a variety of configurations, including pistol grip, angle wrench and ETS
Product Overview
The innovative QX Connect Series™ from Ingersoll Rand offers closed-loop control of your fastening process, and the ease of mobility with different connectivity options. Each and every tool allows for programmable tightening strategies to deliver higher quality fastened joints and a level of control that is unmatched by other solutions. The diversity of the QX Series™ lineup offers a simple, flexible and capable solution for any fastening need.
- Torque range from 0.8 to 80 Nm or 2.95 to 239 in-lbs
- Drive sizes of 1/4", 3/8" and 1/2"
- Multi-function display module for quick setup and feedback
Product resources
Technical specifications
| Series | Torque range Nm | Torque range in.lb | Configuration | Drive size | Free speed RPM | Communication | Display | Weight kg |
|---|---|---|---|---|---|---|---|---|
| QX Series ETS | 1.6 - 80 | 5.9 - 239 | Pistol-ETS & Right Angle-ETS | - | - | - | - | - |
| QXFN Angle Wrench | 1 - 27 | 9 - 239 | Right Angle & Right Angle-ETS | 1/4" & 3/8" | 1213 | USB | No | 1.68 |
| QXFN High Torque Angle Wrench | 4 - 80 | 2.9 - 59 | Right Angle & Right Angle-ETS | 3/8" & 1/2" | 1045 | USB | No | 2.27 |
| QXFN Screwdriver | 0.8 - 24 | 7 - 212 | Pistol & Pistol-ETS | 1/4" & 3/8" | 1500 | USB | No | 2 |
| QXFD High Torque Angle Wrench | 4 - 80 | 2.9 - 59 | Right Angle & Right Angle-ETS | 3/8" & 1/2" | 1045 | USB | Yes | 2.27 |
| QXFD Screwdriver | 0.8 - 24 | 7 - 212 | Pistol & Pistol-ETS | 1/4" & 3/8" | 1500 | USB | Yes | 2 |
| QXBN Angle Wrench | 0.8 - 27 | 7 - 239 | Pistol & Right Angle | 1/4" & 3/8" | 1500 | Bluetooth & USB cable | No | 1.68 |
| QXBN High Torque Angle Wrench | 4 - 80 | 2.9 - 59 | Right Angle & Right Angle-ETS | 3/8" & 1/2" | 1045 | Bluetooth & USB cable | No | 2.27 |
| QXBN Screwdriver | 0.8 - 24 | 7 - 212 | Pistol & Pistol-ETS | 1/4" & 3/8" | 1500 | Bluetooth & USB cable | No | 2 |
| QXBD Angle Wrench | 0.8 - 27 | 7 - 239 | Right Angle & Right Angle-ETS | 1/4" & 3/8" | 1500 | Bluetooth & USB cable | Yes | 1.68 |
| QXBD High Torque Angle Wrench | 4 - 80 | 2.9 - 59 | Right Angle & Right Angle-ETS | 3/8" & 1/2" | 1045 | Bluetooth & USB cable | Yes | 2.27 |
| QXBD Screwdriver | 0.8 - 24 | 7 - 212 | Pistol & Pistol-ETS | 1/4" & 3/8" | 1500 | Bluetooth & USB cable | Yes | 2 |
| QXXN Angle Wrench | 1 - 27 | 9 - 239 | Right Angle & Right Angle-ETS | 1/4" & 3/8" | 1213 | Wireless & USB | No | 1.68 |
| QXXN High Torque Angle Wrench | 4 - 80 | 2.9 - 59 | Right Angle & Right Angle-ETS | 3/8" & 1/2" | 1045 | Wireless & USB | No | 2.27 |
| QXXN Screwdriver | 0.8 - 24 | 7 - 212 | Pistol & Pistol-ETS | 1/4" & 3/8" | 1500 | Wireless & USB | No | 0.91 |
| QXXD Angle Wrench | 1 - 27 | 9 - 239 | Right Angle & Right Angle-ETS | 1/4" & 3/8" | 1213 | Wireless & USB | Yes | 1.68 |
| QXXD High Torque Angle Wrench | 4 - 80 | 2.9 - 59 | Right Angle & Right Angle-ETS | 3/8" & 1/2" | 1045 | Wireless & USB | Yes | 2.27 |
| QXXD Screwdriver | 0.8 - 24 | 7 - 212 | Pistol & Pistol-ETS | 1/4" & 3/8" | 1500 | Wireless & USB | Yes | 2 |
