Drills | Ingersoll Rand | Assembly Solutions | HES
Ingersoll Rand product

Drills

  • Broad range of speeds, torques, clutches and throttle handles
  • Heavy-duty double-row spindle for accurate holes and less damage to parts
  • Ergonomic design with cantilever mounted planet gears reduces fatigue and improves production
Enquire now

Product Overview

The Ingersoll Rand suite of handheld and fixtured drills offer the speed, power and accuracy to deliver true holes, day in and day out. Our handheld drills feature compact size, superior ergonomics and excellent power-to-weight ratios.

Product resources

  • Chuck capacity up to 1/2"
  • Free speed up to 6000 RPM

Pneumatic & Cordless Drills

SeriesBit holder/Chuck capacityConfigurationActuationFree speed RPMWeight kg
1 Series Inline1/4"InlineLever30000.54
1 Series Angle1/4"AngleLever37000.51
1 Series Pistol-Grip1/4"PistolTrigger38000.68
5 Series Non-Reversible Pistol1/4" & 3/8"PistolTrigger45001.3
5 Series Non-Reversible Inline1/4"InlineLever31000.09
5 Series Angle1/5", 1/4" & 3/8"AngleLever30001.6
5 Series Reversible Pistol3/8" & 1/2"PistolTrigger20001.4
7 Series Tappers0.9"Pistol-4751.5
7 Series Pistol-Grip1/4", 3/8" & 1/2"PistolTrigger60001.5
7 Series Angle3/8" & 1/2"AngleLever9001.9
78023/8"PistolTrigger20001.2
1/2" Air Drill1/2"PistolTrigger5001.5
1/4" Mini Air Drill1/4"PistolTrigger18750.82
3/8" Right Angle Air Drill3/8"AngleLever18001.1
Q2 Angle1/4" & 3/16"AngleLever27000.6
Q2 Inline1/4"InlineLever51000.62
Q2 Pistol-Grip1/4" & 3/8"InlineTrigger51000.8
Q2 Tappers1/4"Pistol-10000.9
ATEX Reversible3/8" & 1/2"PistolTrigger20001.5
20V Cordless Drill3/8"PistolTrigger4000.88
LA4103/8"StraightTrigger45000.91

Precision Drills

SeriesSpeed RPMTorque NmMax capacity mmAir consumption l/sWeight kg
P33N DASL Non-Modular 180°5400166.4100.88
P33N DASL Non-Modular 30°5400166.4100.81
P33N DASL Non-Modular 90°5400166.4100.81
P33N DMSL Modular Straight540016100.63
P33N DSL Non-Modular Straight180001610100.78
P33N PMSL Modular Pistol540016100.82
P33N PSL Non-Modular Pistol540016100.95
