Introducing the HEP1 Series Electric Compact Pumps from Hi-Force

Designed for a wide range of industrial applications, the HEP1 Series offers robust performance, flexible configuration options, and convenient transportability.

Featuring an efficient two-stage pump design, the HEP1 delivers fast operation and reliable high-pressure performance. The 1st stage delivers oil up to 2.6 litres per minute, while the 2nd stage delivers 0.36 litres per minute for precise high-pressure operation (60 Hz models deliver approximately 15-20% higher flow rates). HEP1 pumps operate up to a maximum working pressure of 700 bar and include an automatic low-to-high pressure changeover for seamless performance.

The HEP1 Series is available with a choice of electric motors and control valve configurations, allowing users to tailor the pump to their specific operational requirements. Its compact construction and integral carrying handle make transportation easy, while the rugged design and IP55 rating keep it running in the toughest industrial environments.

Key features of the HEP1 Series include:

• Usable oil reservoir capacity of 4 litres
• Choice of 110V 50 Hz, 120V 60 Hz, 230V 50 Hz, and 220V 60 Hz single-phase electric motors
• Choice of 3-way dual-purpose valve (advance/auto-retract for crimping and cutting, or advance/hold/retract for lifting applications) and 4-way manual valve with load-holding capability
• 3-way and 4-way valve options available with or without an externally adjustable pressure relief valve and pressure gauge
• Internal pressure relief valve factory-set to 700 bar
• Remote hand pendant controller with 3-metre control cable
• IP55 ingress protection rating

With 16 models and multiple configuration options available, the HEP1 Series delivers outstanding versatility, making it the ideal hydraulic power source for a wide range of demanding industrial applications.
