Balancers | Ingersoll Rand | Lifting and Material Handling | HES
Ingersoll Rand product

Balancers

  • Suitable for continuous duty with minimal maintenance and ideal for applications where precision spotting is necessary
  • Low air consumption and clean, oil-free operation
Enquire now

Product Overview

Ingersoll Rand balancers allow users to not only lift the load but also “float" the load, allowing for precise manual movement and placement without the “jogging" required with traditional hoists.

Product resources

  • Capacity range of 50 to 2000 lbs (22 to 900 kg)
  • Cable travel from 40" to 120" (1016 to 3048 mm)

Zero Gravity Balancers

SeriesLoad capacity kgWire rope stroke mWeight kg
Zero Gravity68 - 2252 - 352

Pneumatic Balancers

SeriesCapacityVertical travelDiameter of balancerWeight kg
ZA68 - 900 kg 150 - 2000 lbs1016 - 3048 mm 40" - 120"Up to 254 mm / 10"225
BA22 - 900 kg 50 - 2000 lbs1016 - 3048 mm 40" - 120"Up to 260 / 10.24"225
EA68 - 900 kg 150 - 2000 lbs1016 - 3048 mm 40" - 120"Up to 254 mm / 10"225
B68 - 900 kg 150 - 2000 lbs1016 - 3048 mm 40" - 120"Up to 254 mm / 10"225
IA68 - 454 kg 150 - 1000 lbs883 - 2896 mm 35" - 114"Up to 254 mm / 10"57
IB68 - 454 kg 150 - 1000 lbs883 - 2896 mm 35" - 114"Up to 254 mm / 10"57
IC68 - 454 kg 150 - 1000 lbs883 - 2896 mm 35" - 114"Up to 254 mm / 10"57
IS68 - 454 kg150 - 1000 lbs883 - 2896 mm35" - 114"Up to 254 mm / 10"57
