Börkey product

Model A

For short displacement routes
transports heavy loads in mining,steel,machine,and bridge construction or as heavy roller conveyors
particularly stable construction through contiuous cover plate
can be bolted to the load

Product Overview

Model A-H (with hardened center plate) is used when the rollerskate is not moved under high load for a long time. As a result, a pressing of the hardened steel rolls is prevented in the standard non hardened center plate and ensures a uniformly low rolling resistance. Model A-H-50CrV4 (roll material 50CrV4) is recommended if the risk of short term overload beyond the specified bearing capacity of the rollerskates can not be excluded or is probable.

Robust overall construction (frame construction)
Low overall height with high load capacity, identical in dimensions with AS+AM series
Firm connection, because the load or cover plate can be screwed

Product resources

Model A Catalogue Page

Supporting rolls	Roll number	Capacity max kN	Weight kg
5	15	150	8.9
4	13	200	11.7
4	13	400	19.3
6	17	500	29.0
4	13	650	51.0
6	17	850	92.0

Dimensions (mm)

Size	a	b	c	Ød	e	f	g	h	Øi	k	l
I	210	100	175	18	51	6	13	76	14	140	75
II	220	113	190	24	60	10	14	87	14	155	75
III	270	130	210	30	68	10	14	104	18	175	95
IIIV	320	140	220	30	68	10	18	115	18	180	120
IV	380	168	270	42	76	19	19	145	22	220	140
V	530	182	300	50	86	19	19	165	22	240	205
